MC -2/X-MT & MCE -2/X-MT
MC
-2/X-MT
&
MCE
-2/X-MT
- Reference Standard
IS-1293, IEC-320, IEC-884, IEC-799, IEC-227
Specification
Electrical Characteristics
Electrical
Characteristics
Parameters
Specification
Product Category / Description
Cable with Mains Connector
V/A Rating (Standard)
For MC-2 4A, 250 V AC & For MCE-2 6A, 250 V AC.
Insulation Resistance at 500 V DC
100 Mega Ohms Min.
H.V.Break Down Test (For 1 Minute)
1.5 KV AC
Conductor Resistance per meter
For MC-2,39 m ohm max. & For MCE-2 26 m ohms max.
Operating/Functional Characteristics
Operating/Functional
Characteristics
Parameters
Specification
Operating Temp. Range
-20°C TO +85°C
Length (L), Meters
As per requirement. Standard = 1.5. Other - 2.0, 2.5, 3.0. Please specify.
Material
Material
Parameters
Specification
Cable
PVC
Conductors
Copper
Conductors (Size)
For MC-2 -0.50 sq.mm (16x0.2) & For MCE-2 0.75 Sq.mm (24x0.2)
Contacts
Brass, Nickel plated
Reference Standards
Reference
Standards
Parameters
Specification
Reference Standards
IEC-60320-1,IEC-60320-3,IEC-60799, IEC-60227
Compliance marking
CE, RoHS (on request)
Data Sheet
Elcom MC-2-Slash-MCE-2-Slash-X-MT-1 6 Data Sheet
436 KB
