EB03
EB03
Specification
- Reference Standard
EN60939-3:2015 & EN60939-2:2005 standards.
- EB03 Approval
CSA, ROHS, CE
Specification
Technical Specification
Technical
Specification
Parameters
Specification
Operating voltage
120/250 VAC
Current rating
1A-10A
Frequency
50/60Hz
Voltage drop
1 Volt max.
High potential test voltage
P -> E 1500VAC P -> N 1414VDC (applicable excluding surge suppressor filter)
Insulation resistance
≥ 300 MΩ @ 500VDC (PN→E)
Operating temperature
40°c /-25°c +85°c
Safety Approvals
Safety
Approvals
Parameters
Specification
CE marking
Yes
cCSAus
Yes
Features
Features of EB03 Filter
Features
of
EB03
Filter
All filters provide high attenuation performance.
Filter available in panel mounting provision.
Single stage and High reliable.
CRCA metal can with nickel plating provides good aesthetic and corrosion protection.
Benefits
Benefits of EB03
Benefits
of
EB03
- Filters available in medical version without capacitor to earth. With surge suppressor filters also available.
- Input connection through IEC 60320 C14 plug..
- Output connection with fast-on or wire terminal.
- Applications - Portable electrical and electronic equipment, Datacom equipment, Rack mounting equipment, Control Panel, Medical equipment, Consumer product, Medical equipment, Industrial application, Electrical automation equipment, Test and measurement equipment
Download PDF
Elcom EB03 Filter
508 KB
